VHB™ 7100075331

VHB™ 7100075331 4926 Tape, 72 yd L 0.5 in W, 15 mil THK, Acrylic Foam Backing, Gray

Select Your Options

Item ID: 10007331
MPN: 7100075331
Sold As: 1/RL

Your Price:

Availability:
Estimated availability:
Average Lead Time:
Quantity:
Add to cart
Add to Shopping List

FEATURES
Documents
TECHNICAL SPECIFICATIONS
DESCRIPTION

SMOOTH AND SEAMLESS - With a thickness of 15 mil (0.4 mm), this tape is designed as an alternative to mechanical fasteners, such as rivets, welds, and screws, or liquid adhesives
BUILT TO PERFORM - Delivers excellent shear strength, conformability, and surface adhesion thanks to an acrylic foam core and multi-purpose adhesive
MULTI-SURFACE - Intended to adhere to a variety of High Surface Energy (HSE) and Medium Surface Energy (MSE) substrates, these may include aluminum, stainless steel, galvanized steel, acrylic, polycarbonate, and ABS
DURABLE - Offers excellent outdoor durability and performance, resisting both high and low temperatures, as well as moisture
FAST AND EASY-TO-USE - A permanent bonding method that provides immediate handling strength, no need to fixture or wait for a cure

Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7100139494_User_Manual.pdf
Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/VHB_7000049210_Technical_Bulletin.pdf

Adhesive Material	Acrylic
Backing Material	Acrylic Foam
Color	Gray
Length	72 yd
Liner Material	54# Densified Kraft Paper
Maximum Operating Temperature	300 deg F
Minimum Operating Temperature	200 deg F
Series	4926
Thickness	15 mil
Type	Pressure Sensitive
Width	0.5 in

3M™ VHB™ Tape 4926 is a double-sided tape comprised of a multi-purpose acrylic adhesive with a conformable, foam core backed on a 3 mil thick 54# densified kraft paper liner, delivering a total thickness of 15 mil (0.4 mm) when applied. This tape provides an excellent balance of strength, conformability, and adhesion to high and medium surface energy materials, making it a smooth, seamless alternative to rivets, welds, and screws. These unique attributes equip 3M™ VHB™ Tape 4926 to take on many bonding and sealing applications, including attaching metal panels to frames and stiffener attachment. Discover new ways to design thanks to the versatility, viscoelasticity, and powerful bonding potential of 3M™ VHB™ Tape 4926.

VHB™, 7100075331, Tape, Series: 4926, 72 yd Length, 0.5 in Width, 15 mil Thickness, 54# Densified Kraft Paper Liner, Gray, Acrylic Foam Backing, 300 deg F Maximum Operating
