3M™ DBI-SALA® 7100252859

3M™ DBI-SALA® 7100252859 M100 Portable Jib Base, 4.5 ft H, 310 lb Load

Select Your Options

Item ID: 8530870
MPN: 7100252859
Sold As: EACH

Your Price:

Availability:
Estimated availability:
Average Lead Time:
Quantity:
Add to cart
Add to Shopping List

FEATURES
Documents
TECHNICAL SPECIFICATIONS
DESCRIPTION

Powder coated steel upright and gusset components
Extended rail-length increases safe working area compared to our previous jib systems
Automatic mast lock helps prevent uncontrolled mast movement
Aluminum extruded trolley rail with stainless steel / nylon trolley construction
Rotating mast up to 360 deg with Flip up rotation handle
Permanent and portable mounted designs available
Power assisted height adjustment capability for adjustable models
Leveling jacks standard on the M100 with integrated fork pockets for transporting and positioning using industrial forklifts
Additional system mobility with optional caster wheel kit

Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_DBI_SALA_7100306797_User_Manual.pdf

Height	4.5 ft
Load Capacity	310 lb
Series	M100
Type	Portable

The 3M™ DBI-SALA® Flexiguard™ Modular Jib System is comprised of a modular set of components that when properly configured constitute a unique overhead anchorage system. The 3M™ DBI-SALA® FlexiGuard™ M100 Portable Counterweight Bases design with removable counterweight box enables easier system mobility with a forklift.

3M™ DBI-SALA®, 7100252859, Jib Base, Portable, Series: M100, 4.5 ft Height, 310 lb Load
